50kw High Frequency Induction Heating Machine Intelligent induction hardening equipment

China Zhengzhou Lanshuo Electronics Co., Ltd certification
China Zhengzhou Lanshuo Electronics Co., Ltd certification
машина индукционного нагрева хороша, я доволен этим.

—— Жүгнээ Цогбадрах

Je suis satisfait du four de fusion par induction, j'espère coopérer à l'avenir.

—— amine ouarroch

I'm Online Chat Now

50kw High Frequency Induction Heating Machine Intelligent induction hardening equipment

50kw High Frequency Induction Heating Machine Intelligent induction hardening equipment
50kw High Frequency Induction Heating Machine Intelligent induction hardening equipment
video play

Large Image :  50kw High Frequency Induction Heating Machine Intelligent induction hardening equipment

Product Details:
Place of Origin: China
Brand Name: Lanshuo
Certification: CE ISO
Model Number: LSW-50
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 1000-1600 / set
Packaging Details: 1.Standard wooden case, plywood case, and custormized case; 2. Inner packing: packing plastic film and foam in case of friction dampness and shake; 3.Accessories: induction coil 1, foot pedal 1, installing and operating instruction 1 and custormized del
Delivery Time: 5-7 working days after receiving advanced payment
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 2000 set per year
Detailed Product Description
Type: Induction Quenching Equipment Voltage: 380V
Current: 75A Rated Capacity: 50kw
Rated Duty Cycle: 100% Dimension: 550*650*1260mm
Weight: 120kg Usage: Brazing, Welding,heating
Power: 50kw Color: Optional
High Light:

50kw High Frequency Induction Heating Machine

,

Intelligent High Frequency Induction Heating Machine

,

50kw Induction Hardening Equipment

50kw High Frequency Intelligent Digital Induction Heating Quenching hardening Machine

1. Main Feature of induction quenching machine:
Induction quenching machine adopts the IGBT inverter circuit in parallel connection, which has high load adaptability.
The comprehensive full load design is available for 24-hour continuous operation.
The digital phase locked realizes following frequency automatically.
Design in modules. It is installed facility and use conveniently without debugging..
The perfect protection function, insuring the reliability and easily maintaining of the equipments.
The technique of converting frequency by resonance promotes efficiency of whole equipment by over 95%.
Economy and environment protection, it can replace of gas/coal/electronic tube induction heating machine.

50kw High Frequency Induction Heating Machine Intelligent induction hardening equipment 0
2. Technical Parameters of LSW-50 Induction Quenching Equipment:

Model LSW-50
Working Voltage 380V, 50/60HZ
Max input power 50kw
Oscillation frequency 18-35KHZ
Duty cycle 100%
Cooling water flow 32L/Min,0.1MPa
Weight 120kg
Dimension (L*W*H ) 550*650*1260mm
Material stainless steel
Color support customized
Usage metal heating, brazing,melting etc

3. Main characteristics of LSW-50 Induction Quenching Equipment:
(1) High efficiency: Metal can be heated to its desired temperature, even its melting point, instantly.
(2) Energy saving: The induction brazing machine adopts IGBT from Siemens & LC series circuit design, saving energy up to 15%-30%.
(3) Low cost: The heating time is short, compared to other heating methods, significantly reducing the amount of metal loss.
(4) Easy for installation: Following the user manual, even non-professional persons can install the induction brazing machine easily.
(5) Stable operation: complete protection, make customers have nothing to worry about.
(6) No harm to the environment: The induction brazing machine uses electricity, producing little waste gas and water.

4. Induction Quenching Equipment Application:
50kw High Frequency Induction Heating Machine Intelligent induction hardening equipment 1
Heat treatment:such as Quenching, Annealing
Heat treatment process is the metal work-pieces heated to a certain temperature, obtained different matrix organization after different ways of cooling, so that to achieve the required mechanical properties (material harder or softer), such as quenching, annealing, etc.
Applications Examples: Shaft, Shaft core, Plate, Gear, Sprocket, Steel belt, Machine tool accessories, Guide rail, Hardware tools, Small mold, Mold accessories, CAM, Automobile and motorcycle accessories, Scissors, Garden shears blade, Chuck, mechanical parts, Stainless steel products, Cistern, Kitchen ware, Golf head, Clubs, Steel tube, Furniture fittings and Other related products.

50kw High Frequency Induction Heating Machine Intelligent induction hardening equipment 2
5.Working Principle Of Induction Equipment Machine:
The flow of high-frequency and high-frequency machine is made of circular or other shape of the heating coil (usually with copper production). A coil which produces changes in the magnetic polarity of the instantaneous beam, the metal object is heated coil placed on the magnetic beam will be heated through the whole object, the object being heated inside the heating current in the opposite direction, there will corresponding large eddy currents. Because of the heated object memory in the resistance, it will have a lot of Joule heat, so that the rapid rise in body temperature itself. Metallic material is heated to achieve for all purposes.
50kw High Frequency Induction Heating Machine Intelligent induction hardening equipment 3

How to choose induction heating equipment?
1. The shape and size of the workpiece to be heated:
The large workpiece, bar stock, solid material should choose the Induction heating equipment with relatively large power, low frequency.
The small workpiece, pipe, plate, gear, etc., should choose the Induction heating equipment with relatively small power, the high frequency.

2. Depth and area to be heated:
Deep heating depth, large area, overall heating, should choose high power, low frequency induction heating equipment;
Shallow heating depth, small area, local heating, choose relatively low power, high frequency induction Heating equipment.

3, The required heating rate:
Requiring fast heating speed, should use relatively large power, relatively low frequency induction heating equipment.
