Large Melting Furnace
>
|
|
| Place of Origin | China |
| Brand Name | Lanshuo |
| Certification | CE, ISO |
| Model Number | KGPS-200KG |
The Induction Melting Furnace is a high-quality and efficient machine designed for melting metal in foundries and heat treatment facilities. With a melting capacity of 1-250kg, it is suitable for a wide range of applications and can handle both small and large batches of metal.
The average melting time for this furnace is 20-30 minutes, providing quick and efficient melting for your production process. This allows for a smooth and continuous workflow, saving you time and increasing productivity.
The Induction Melting Furnace operates at a voltage of 380V and a frequency of 50/60HZ, making it compatible with most power sources. It can also work continuously for 24 hours, ensuring uninterrupted production and meeting the demands of a fast-paced work environment.
This furnace utilizes a water cooling method, which helps to maintain a stable temperature and prevent overheating. This ensures the longevity of the machine and provides a safe and controlled environment for melting metal.
| Article | KGPS-100KW | KGPS-160KW | KGPS-200KW |
| Rated capacity | 100KG/H | 150KG/H | 250KG/H |
| Rated power | 100KW | 160KW | 200KW |
| Transformer capacity | 150KVA | 200KVA | 250KVA |
| Input voltage | 380V 50-60HZ | 380V 50-60HZ | 380V 50-60HZ |
| Frequency -MF | 2000HZ | 2000HZ | 2000HZ |
| -MF Voltage | 750V phase | 750V phase | 750V phase |
| Voltage-DC | 500V phase | 500V phase | 500V phase |
| Current-DC | 200A phase | 320A phase | 400A phase |
| Nominal temperature | 1800 ℃ | 1800℃ | 1800℃ |
| Fusion time | 20-40min | 20-40min | 20-45min |
| Closed cooling tower (circulating water) | LSN-10T/H | LSN-20T/H | LSN-20T/H |
| KGPS Fast Medium Frequency Power Supply | 1 set | 1 set | 1 set |
| Oven | one | one | one/two |
| Reducer | RZS231 1 set | RZS231 1 set | RZS231 1 set |
| water cooled cable | 180mm² *2 | 185mm² *2 | 240mm² *2 |
| crucible mold | 1 | 1 | 1 |
| Specification information | 1 | 1 | 1 |
1. High melting rate.
2. Good-quality molten steel, high casting product yield.
3. High power factor. During the machine’s operation, the power factor can reach over 97%.
4. No harm to the power gird.
5. Low power consumption, saving over 10% energy.
6. High start-up success rate. Under any load, the start-up success rate is 100%.
7. The main control panel adopts plug-in connector, easier maintenance.
8. Simple to install. Installation can be done by unprofessional workers very easily.
9. The melting furnace adopts series thyristor, making the SCR damage rate to a minimum.
The Induction Melting Furnace is widely used in the metal processing industry for melting, heating, and heat treatment purposes. It is suitable for melting a variety of metals such as gold, silver, copper, iron, steel, and aluminum.
Induction Melting Furnace is packaged in a sturdy wooden crate to ensure safe transportation and delivery. The crate is lined with protective foam and the furnace is securely strapped and cushioned to prevent any damage during shipping.
The crate is then labeled with handling instructions and product information for easy identification. Each package is also carefully inspected before shipping to ensure that all necessary components and accessories are included.
For international shipping, the furnace is packed in compliance with all relevant customs regulations to facilitate smooth clearance at the destination. We work closely with trusted shipping partners to ensure timely and efficient delivery to our customers worldwide.
