| Type: | Induction Melting Furnace | Power: | 90kw |
|---|---|---|---|
| Input Current: | 140A | Voltage: | 3-phase 380v, 50/60hz |
| Oscillation Frequency: | 1-15KHZ | Connecting Wire: | 75mm2 |
| Control Switch: | 3*225A | Ground Wire: | 2mm2 |
| Cooling Water Pressure: | ≥0.2MPa | Cooling Water Flow: | ≥20L/Min |
| Color: | Customizable | Size: | 760*400*880mm/550*400*500mm |
| Weight: | 97kg | ||
| High Light: | induction melting machine,medium frequency induction melting furnace |
||
1. Melting Capacity of Gold Aluminum Iron Steel Silver Induction Melting Furnace:
|
||||||||||||||||||||||||||||||||||||||||||||||||
2. Gold Aluminum Iron Steel Silver Induction Melting Furnace Application:
3. Main technical parameters of LSZ series induction melting furnace:
| Model | Power | Input current | Voltage | Oscillation frequency |
Connect- ing wire |
Control switch |
| LSZ-15 | 15kw | 18A | 3-phase 380 V, 50/60 Hz | 1-15KHz | 10mm2 | 3*40A |
| LSZ-25 | 25kw | 36A | 10mm2 | 3*60A | ||
| LSZ-35 | 35kw | 57A | 16mm2 | 3*80A | ||
| LSZ-45 | 45kw | 80A | 35mm2 | 3*120A | ||
| LSZ-70 | 70kw | 110A | 50mm2 | 3*150A | ||
| LSZ-90 | 90kw | 140A | 75mm2 | 3*225A | ||
| LSZ-110 | 110kw | 160A | 90mm2 | 3*225A | ||
| LSZ-160 | 160kw | 240A | 120mm2 | 3*300A |
4. Packaging of Gold Aluminum Iron Steel Silver Induction Melting Furnace:
5. Company Brief Introduction :
6. Customer Center:
7. Canton Fair
8. Trade Process:
