45kw Induction Melting Furnace for Iron Steel Copper Gold Silver
  • 45kw Induction Melting Furnace for Iron Steel Copper Gold Silver
  • 45kw Induction Melting Furnace for Iron Steel Copper Gold Silver
  • 45kw Induction Melting Furnace for Iron Steel Copper Gold Silver
  • 45kw Induction Melting Furnace for Iron Steel Copper Gold Silver
  • 45kw Induction Melting Furnace for Iron Steel Copper Gold Silver
45kw Induction Melting Furnace for Iron Steel Copper Gold Silver

45kw Induction Melting Furnace for Iron Steel Copper Gold Silver

Place of Origin China
Brand Name Lanshuo
Certification CE
Model Number LSZ-45
Product Details
Type:
Induction Melting Furnace
Application:
Smelting Iron Steel Copper Brass Gold Silver Aluminum
Rated Power:
45kw
Input Current:
80A
Voltage:
3-phase 380v, 50/60hz
Oscillation Frequency:
1-15KHZ
Connecting Wire:
35mm2
Control Switch:
3*120A
Ground Wire:
2mm2
Cooling Water Pressure:
≥0.2MPa
Cooling Water Flow:
≥15L/Min
Gross Dimension:
1250*840*1000mm / 720*440*630mm
Gross Weight:
250kg
Highlight:

Iron Smelting Induction Melting Furnace

,

10kg Iron Smelting Induction Melting Furnace

,

50kg Iron Smelting Induction Melting Furnace

Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
USD 4000---5000 / set
Packaging Details
plywood case, 2 packages, 1250*840*1000mm / 720*440*630mm
Delivery Time
5-10 working days after receiving advanced payments
Payment Terms
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability
2000 sets per year
Product Description
10kg 20kg 30kg 50kg Iron Smelting Furnace Induction Melting Furnace
Product Specifications
Attribute Value
Type Induction Melting Furnace
Application Smelting iron, steel, copper, brass, gold, silver, aluminum
Rated Power 45kw
Input Current 80A
Voltage 3-phase 380v, 50/60hz
Oscillation Frequency 1-15KHZ
Connecting Wire 35mm²
Control Switch 3*120A
Ground Wire 2mm²
Cooling Water Pressure ≥0.2MPa
Cooling Water Flow ≥15L/Min
Gross Dimension 1250*840*1000mm / 720*440*630mm
Gross Weight 250kg
45kw Electric Smelting Furnace Induction Melting Furnace
Introduction

Medium frequency induction melting furnace adopts IGBT as the core inverter. Alternating current in the coils melts the metals in the crucible and then heats the hot metal to the temperature needed. It is the heat treatment prior to forging, sintering and hot rolling in casting and melting industries.

45kw Induction Melting Furnace for Iron Steel Copper Gold Silver 0
Applications

The LSZ series induction melting furnace can melt the following materials:

  • Iron, pig iron, cast iron
  • Steel, stainless steel, cast steel, carbon steel and bearing steel
  • Precious metals like gold and silver
  • Copper, brass, bronze
  • Aluminum, aluminum alloy
  • Zinc, lead, tin, magnesium, nickel, titanium
45kw Induction Melting Furnace for Iron Steel Copper Gold Silver 1
Melting Capacity
Model Rated Power Steel, Stainless Steel Copper, Gold, Silver Aluminum, Aluminum Alloy
LSZ-15 15kw 3kg 10kg 3kg
LSZ-25 25kw 5kg 20kg 5kg
LSZ-35 35kw 10kg 30kg 10kg
LSZ-45 45kw 18kg 50kg 18kg
LSZ-70 70kw 25kg 100kg 25kg
LSZ-90 90kw 40kg 120kg 40kg
LSZ-110 110kw 50kg 150kg 50kg
LSZ-160 160kw 100kg 250kg 100kg
Technical Parameters
Model Power Input Current Voltage Oscillation Frequency Connecting Wire Control Switch
LSZ-15 15kw 18A 3-phase 380V, 50/60 Hz 1-15KHz 10mm² 3*40A
LSZ-25 25kw 36A 3-phase 380V, 50/60 Hz 1-15KHz 10mm² 3*60A
LSZ-35 35kw 57A 3-phase 380V, 50/60 Hz 1-15KHz 16mm² 3*80A
LSZ-45 45kw 80A 3-phase 380V, 50/60 Hz 1-15KHz 35mm² 3*120A
LSZ-70 70kw 110A 3-phase 380V, 50/60 Hz 1-15KHz 50mm² 3*150A
LSZ-90 90kw 140A 3-phase 380V, 50/60 Hz 1-15KHz 75mm² 3*225A
LSZ-110 110kw 160A 3-phase 380V, 50/60 Hz 1-15KHz 90mm² 3*225A
LSZ-160 160kw 240A 3-phase 380V, 50/60 Hz 1-15KHz 120mm² 3*300A
Key Features
  • IGBT module imported for superior performance
  • Higher reliability and lower maintenance cost
  • 100% Duty cycle - continuous working at maximum output power
  • Displays heating power, heating current and oscillation frequency
  • Simple installation that can be done by unprofessional persons
  • Convenient crucible changing for different melting materials
  • Continuous heating ability for 24 hours
Factory Photos
45kw Induction Melting Furnace for Iron Steel Copper Gold Silver 2
Certifications
45kw Induction Melting Furnace for Iron Steel Copper Gold Silver 3 45kw Induction Melting Furnace for Iron Steel Copper Gold Silver 4 45kw Induction Melting Furnace for Iron Steel Copper Gold Silver 5
