Medium Frequency 30kw Electric Induction Melting Furnace For Melting Metal

Medium Frequency 30kw Electric Induction Melting Furnace For Melting Metal
Medium Frequency 30kw Electric Induction Melting Furnace For Melting Metal Medium Frequency 30kw Electric Induction Melting Furnace For Melting Metal Medium Frequency 30kw Electric Induction Melting Furnace For Melting Metal

Large Image :  Medium Frequency 30kw Electric Induction Melting Furnace For Melting Metal

Product Details:
Place of Origin: China
Brand Name: Lanshuo
Certification: CE ISO
Model Number: LSW-30 Induction Melting Machine
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 1000-3000 / set
Packaging Details: wooden case
Delivery Time: 5-7 working days after receiving advanced payment
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 Set/Sets per Year
Detailed Product Description
Type: Induction Melting Machine Usage: Heating Melting Brazing Welding
Voltage: 380v Power: 30kw
Input Voltage: Triphase 380v 50-60 Hz Oscillation Frequency: 25-40Khz
Color: Optional
High Light:

30kw Electric Induction Melting Furnace

,

Metal Electric Induction Melting Furnace

,

30kw medium frequency induction melting furnace

Small medium frequency electric induction melting furnace for melting metal

1. Brief Introduction of Induction Melting Machine:
Induction smelting furnace adopts the principle of magnetic induction eddy current heating and use electric current to generate magnetic field through coil. When magnetic field line passes through metal material in magnetic field, it makes boiler body heat at high speed on its own, and then heat material again. And in short time, it reaches the required temperature.

Our high frequency induction melting furnace adopts IGBT series and parallel induction heating technology as the core. Alternating current in the coils melts the metals in the crucible and then heats the hot metal to the temperature needed. It is the heat treatment prior to forging, sintering and hot rolling in casting and melting industries.

melting mainly aims to melt the metal into liquid by using the high temperature, which is applicable to the smelting of iron, steel, copper, aluminum, zinc as well as various noble metals.

Medium Frequency 30kw Electric Induction Melting Furnace For Melting Metal 0
2. Technical Parameters of LSW-30 Induction Melting Machine:

Modle LSW-30KW
Input Power: 30KW
Input voltage: three phase 380v 50hz
Voltage range: 340V~420V
Oscillation frequency: 25-35Khz
Current(max): 52A
continuous load rate: 100%
Cooling water flow(controller) 25L/Min 0.1mpa
Weight 48kg
Dimension 265*600*540mm

3. LSW-30 Induction Melting Machine Application:

(1) iron, pig iron, cast iron;

(2) steel, stainless steel, cast steel, carbon steel and bearing steel;

(3) precious metal such as gold, silver;

(4) copper, brass, bronze;

(5) aluminum, aluminum alloy;

(6) zinc, lead, tin, magnesium, nickel, titanium.

Medium Frequency 30kw Electric Induction Melting Furnace For Melting Metal 1

4. Main Features of induction heating Melting machine:

(1) High efficiency: Metal can be heated to its desired temperature, even its melting point, instantly.
(2) Energy saving: The induction heating machine adopts IGBT from Siemens & LC series circuit design, saving energy up to 15%-30%.
(3) Low cost: The heating time is short, compared to other heating methods, significantly reducing the amount of metal loss.
(4) Easy for installation: Following the user manual, even non-professional persons can install the induction heating machine easily.
(5) Stable operation: complete protection, make customers have nothing to worry about.
(6) No harm to the environment: The induction heating machine uses electricity, producing little waste gas and water.

Medium Frequency 30kw Electric Induction Melting Furnace For Melting Metal 2
5. LSW-30 Induction Heating Melting Machine Advantage:

1. Heating fast and uniform.
2. Machine power can be adjust stable.
3. Easy installation, simple operation.
4. Safe and reliable. No high voltage, very safe for operating people.
5. A unique cooling circulation system, ensure that the equipment 24 hours of continuous work.
6. Environmental. Almost no oxide layer, produced no exhaust, no waste-water is generated.
7. It has complete self-protect functions: such as many types of alarm lamps: over-current, over-voltage, over hot, water shortage etc, can also control and protect itself.
