|Type:||Induction Melting Furnace||Voltage:||380v, 50/60HZ|
|MF Frequency:||2000HZ||Medium Voltage:||750v Phase|
|DC Voltage:||500V Phase||DC Current:||800A Phase|
|Melting Material:||Gold, Silver, Copper, Iron And Aluminum Etc||Rated Power:||400KW|
2000HZ Aluminum Melting Furnace,
800A Aluminum Melting Furnace,
Induction Aluminum Melting Furnace
1. Brief Introduction of Medium Frequency Induction Melting Furnace:
Induction electric furnace steelmaking is more in line with environmental protection requirements,while electric arc furnace steelmaking produces a large amount of exhaust gas, waste residue and noise, and has high energy consumption.
An induction melting furnace is an electrical furnace in which the heat is applied by induction heating of metal.Induction melting furnace capacities range from less than one kilogram to one hundred tonnes, and are used to melt iron and steel, copper, aluminium, and precious metals.
2. Technical Parameter of Large Induction Melting Furnace:
|Matching transformer's capacity||500KVA|
|Medium Voltage||750V Phase|
|DC Voltage||500V Phase|
|DC Current||800A Phase|
|Closed Loop Water Cooling Tower||LSN-30B|
3. Large Induction Melting Furnace Application:
(1) iron, pig iron, cast iron;
(2) steel, stainless steel, cast steel, carbon steel and bearing steel;
(3) gold, silver, platinum;
(4) copper, brass, bronze;
(5) aluminum, aluminum alloy;
(6) zinc, lead, tin, magnesium, nickel, titanium.
4. Feature of Large Induction Melting Furnace :
The intermediate frequency induction melting furnace uses induction heating to heat the metal work-piece itself. At the same time, the furnace body of the intermediate frequency induction smelting furnace is made of thermal insulation materials, so the heat loss is smaller. The non-contact heating of the metal also reduces the energy loss, and the thermal efficiency is as high as about 75%. Under the same conditions, it can save energy by 20%-60% compared with traditional heating equipment. It also greatly reduces the preheating time before metal smelting. . Since the furnace body itself does not produce high temperature during the heating process, the service life of the smelting furnace is prolonged and maintenance costs are reduced.
The advantage of the induction melting furnace is a clean, energy-efficient and well-controllable melting process compared to most other means of metal melting.
medium frequency induction melting furnace heat metal work-pieces by induction heating method. at the same time,furnace body is made of thermal insulation materials,heat loss is much less.
the non-contact heating of metal also reduce the energy loss,thermal efficiency is up to 75%. under the same conditions,it is much more energy-saving by 20%-60% than traditional heating equipment, and it also reduces preheating time before metal melting. During heating process,furnace body itself does not produce high temperature,so it can prolong melting furnace's service life and reduce maintenance costs.
