Type: | Induction Melting Furnace | Voltage: | 380v, 50/60HZ |
---|---|---|---|
MF Frequency: | 2000HZ | Medium Voltage: | 750v Phase |
DC Voltage: | 500V Phase | DC Current: | 800A Phase |
Rated Temperature: | 1600°c | Color: | Customizable |
Melting Material: | Gold, Silver, Copper, Iron And Aluminum Etc | Rated Power: | 400KW |
Rated Capacity: | 0.5T | ||
High Light: | 2000HZ Induction Melting Furnace,400KW Induction Melting Furnace,Aluminum Bronze Induction Melting Furnace |
1. Brief Introduction of Medium Frequency Induction Melting Furnace:
Induction electric furnace steelmaking is more in line with environmental protection requirements,while electric arc furnace steelmaking produces a large amount of exhaust gas, waste residue and noise, and has high energy consumption.
An induction melting furnace is an electrical furnace in which the heat is applied by induction heating of metal.Induction melting furnace capacities range from less than one kilogram to one hundred tonnes, and are used to melt iron and steel, copper, aluminium, and precious metals.
2. Technical Parameter of Large Induction Melting Furnace:
Model | KGPS-0.5T/400KW |
Rated Power | 400kw |
Rated Capacity | 0.5T |
Matching transformer's capacity | 500KVA |
Voltage | 380V, 50/60HZ |
MF Frequency | 2000HZ |
Medium Voltage | 750V Phase |
DC Voltage | 500V Phase |
DC Current | 800A Phase |
Rated Temperature | 1600°C |
Closed Loop Water Cooling Tower | LSN-30B |
3. Large Induction Melting Furnace Application:
Induction furnaces are mainly applied to metal's melting, heating or holding, including all ferrous, nonferrous metal and alloy material, such as iron, steel, copper ,aluminum, zinc, tin, nickel, gold,silver, etc.
(1) iron, pig iron, cast iron;
(2) steel, stainless steel, cast steel, carbon steel and bearing steel;
(3) gold, silver, platinum;
(4) copper, brass, bronze;
(5) aluminum, aluminum alloy;
(6) zinc, lead, tin, magnesium, nickel, titanium.
4. Feature of Large Induction Melting Furnace :
1. Be More Safer and Firmer ! Service time can reach 10 years. The furnace body adopted high quality steel structure welding.
2. Energy Saving ! The sensor of the furnace is inclosed with a magnetic yoke covering over 65% to reduce the leakage, being able to save 5% energy consumption.
3. Hydraulic Tilting ! By controlling the buttons and the handle on hydraulic platform, the furnace body can stop in any position, and turn over 95 degrees to pour metal.
4. Power cabinet is adopted by Integrated digital circuit and well-know brands parts, the device have high reliability
5. Rapid heating, temperature easy to control, high production efficiency.
6. The water inlet and outlet of induction melting furnace body adopt water-cooled copper plate to improve the service life of furnace lining.
7. The top of induction melting furnace body is designed with sliding cover design, which makes it more convenient for maintenance personnel to maintain the furnace body.
8. Zero voltage starts up softly, high initial power, don´t impact on the electric network.
It can work for 24hours continuously, can srart or stop at any time;
Less slag, less oxidization loss, its temperature can be control easily by power;
Speedy melting, power saving, no pollution, conforming to environmental protection requirement;
medium frequency induction melting furnace heat metal work-pieces by induction heating method. at the same time,furnace body is made of thermal insulation materials,heat loss is much less.
the non-contact heating of metal also reduce the energy loss,thermal efficiency is up to 75%. under the same conditions,it is much more energy-saving by 20%-60% than traditional heating equipment, and it also reduces preheating time before metal melting. During heating process,furnace body itself does not produce high temperature,so it can prolong melting furnace's service life and reduce maintenance costs.
