30kw Diamond Segment Brazing Induction Welding Machine
  • 30kw Diamond Segment Brazing Induction Welding Machine
  • 30kw Diamond Segment Brazing Induction Welding Machine

30kw Diamond Segment Brazing Induction Welding Machine

Place of Origin China
Brand Name Lanshuo
Certification CE
Model Number LSW-30
Product Details
Induction Brazing Machine
Rated Capacity:
Rated Duty Cycle:
Brazing, Welding,melting
High Light:

Diamond Segment Induction Welding Machine


30kw Induction Welding Machine


Brazing Induction Welding Machine

Payment & Shipping Terms
Minimum Order Quantity
1 set
Packaging Details
1.Standard wooden case, plywood case, and custormized case; 2. Inner packing: packing plastic film and foam in case of friction dampness and shake; 3.Accessories: induction coil 1, foot pedal 1, installing and operating instruction 1 and custormized del
Delivery Time
5-7 working days after receiving advanced payment
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
2000 set per year
Product Description

High Frequency 30kw Electric Diamond Segment induction brazing welding machine


1. Advantage of IGBT Induction Brazing Welding Machine :


Induction brazing can join a wide range of metals, even ferrous to non-ferrous. Induction brazing is precise and quick. Only narrowly defined areas are heated, leaving adjacent areas and materials unaffected. Correctly brazed joints are strong, leak-proof and corrosion resistant. They are also very neat, usually requiring no further milling, grinding or finishing. Induction brazing is ideal for integrating into production lines.


Easy to Check & Adjust Heat, Reduce Overheating Risk, Durable & Efficient. Ideal for Uses in Saw Blades, Carbide Tips, Cooper Tubes, Aluminum Parts & Rotors.


Higher Quality Joints:
One of the primary benefits of induction brazing is that when performed correctly, it produces higher quality joints that are more durable. Brazing machinery and the resulting process results in cleaner, leak-proof joints because they prevent filler materials from flowing into areas where they shouldn't be.


Shorter Heating Cycles:
Compared to other heating applications such as flame brazing, induction heating processes allow more parts to be processed in the same amount of time, which results in faster heating cycles.

30kw Diamond Segment Brazing Induction Welding Machine 0

2. Technical Parameters of LSW-30 IGBT Induction Welding Brazing Machine:

Model LSW-30
Working Voltage 380V, 50/60HZ
Max input power 30kw
Oscillation frequency 25-40KHZ
Duty cycle 100%
Cooling water flow 25L/Min,0.15-0.2MPa
Weight 48kg
Dimension (L*W*H ) 690*290*600mm
Material stainless steel
Color support customized
Usage metal heating, brazing,melting etc


3. IGBT Induction Brazing Welding Machine Application:

Induction brazing systems can be used for virtually any brazing task. To date, our systems are typically used in the electrotechnical industry to braze generator and transfomer components like bars, strands, rings, wires and SC-rings. They also braze fuel pipes and AC and brake parts for the automotive industry. The aeronautics sector uses induction to braze fan blades, blades for casings, and fuel and hydraulic systems. In the houseware industry, our systems braze compressor components, heating elements and faucets.

30kw Diamond Segment Brazing Induction Welding Machine 1

4. Brief Introduction of hot fitting / brazing / welding:

Hot fitting/ brazing/ welding: it mainly refers to the heating of metals between different kinds of metals or between metals and non-metal, using the principle of thermal expansion or thermal melting to connect the two together. For example: the copper core and aluminum pieces of the computer radiator, the embedded welding of speaker net, the composite of the steel-plastic tube, the sealing of the aluminum foil(tooth paste skin), the motor rotor, the sealing of the electric heating tube etc.

30kw Diamond Segment Brazing Induction Welding Machine 2
