1. Melting application of induction melting furnace:
Non-ferrous and ferrous metals melting
Precious metal melting, like gold, sliver, platinum,etc.
Semiconductor material melting
Specialized steel, iron, copper melting
Metal alloy melting, like aluminum alloy, zinc alloy, copper alloy,etc.
Other metal melting applications
metal scrap melting furnace
2. Obvious feature of induction melting furnace:
• Fast melting, Energy-saving, Low pollution.
• There are over 10 safety protection functions like over-voltage, over-current, lack of water, phase loss, tow water pressure, etc.
• Self-developed constant power control board can monitor variation of voltage and current automatically to ensure max melting efficiency.
• 24 hours constant working will meet your long time melting.
• A full year warranty for all machines.
• Meet any melting capacity of metal. From 0.5 kg gold melting furnace to 60 tons steel melting furnace.
2. Melting Capacity of small copper Induction Melting Furnace:
|
3. Electric Small Copper Induction Melting Furnace Application:
4. Electric Small Copper Induction Melting Furnace Feature:
1.Induction heating melting furnace use crucible high temperature to heat metal.then can melt, refine, casting, etc production.
2.Can melt platinum, rhodium and palladium, gold,silver, copper, steel, aluminium, Activated carbon,gold dust sands, electrolysis mud, gold and silver powder, tin ash tin slag etc.
3.Induction heating melting furnace can melt weight from 0.001KG--500KG per time. melting time from 5-40 minutes. max temperature will be 1500C--2000C.
4.Induction heating melting furnace have fixed type,push out type,auto pouring type,furnace up down moving type
5. Main technical parameters of LSZ series Small Copper induction melting furnace:
Model | Power | Input current | Voltage | Oscillation frequency |
Connect- ing wire |
Control switch |
LSZ-15 | 15kw | 18A | 3-phase 380 V, 50/60 Hz | 1-15KHz | 10mm2 | 3*40A |
LSZ-25 | 25kw | 36A | 10mm2 | 3*60A | ||
LSZ-35 | 35kw | 57A | 16mm2 | 3*80A | ||
LSZ-45 | 45kw | 80A | 35mm2 | 3*120A | ||
LSZ-70 | 70kw | 110A | 50mm2 | 3*150A | ||
LSZ-90 | 90kw | 140A | 75mm2 | 3*225A | ||
LSZ-110 | 110kw | 160A | 90mm2 | 3*225A | ||
LSZ-160 | 160kw | 240A | 120mm2 | 3*300A |
1.Ultra-small volume,Easy installation,Easy and safe operation,Easy to change furnace crucible.
2.Higher reliability and lower maintenance cost,High efficiency and energy-saving.
3.100% full load.
4.Equipped temperature system:The machine equipped the temperature control system, which can let you control the temperature going at real time.
5.Display important parameters: Display of heating power and heating current and oscillating frequency.The parameters can be changed conveniently by pressing arrow buttons.
6.Environmental: Almost no oxide layer, produced no exhaust, no waste-water is generated.
7.The types fault protection: About ten types fault protection and display of over-current,over voltage,water shortage and phase missing can provide higher reliability and durability.
