45kw Metal Melting Furnace Iron Steel Copper Gold Silver Melting
  • 45kw Metal Melting Furnace Iron Steel Copper Gold Silver Melting
  • 45kw Metal Melting Furnace Iron Steel Copper Gold Silver Melting
  • 45kw Metal Melting Furnace Iron Steel Copper Gold Silver Melting
  • 45kw Metal Melting Furnace Iron Steel Copper Gold Silver Melting
  • 45kw Metal Melting Furnace Iron Steel Copper Gold Silver Melting
45kw Metal Melting Furnace Iron Steel Copper Gold Silver Melting

45kw Metal Melting Furnace Iron Steel Copper Gold Silver Melting

Place of Origin China
Brand Name Lanshuo
Certification CE
Model Number LSZ-45
Product Details
Type:
Induction Melting Furnace
Application:
Smelting Iron Steel Copper Brass Gold Silver Aluminum
Rated Power:
45kw
Input Current:
80A
Voltage:
3-phase 380v, 50/60hz
Oscillation Frequency:
1-15KHZ
Connecting Wire:
35mm2
Control Switch:
3*120A
Ground Wire:
2mm2
Cooling Water Pressure:
≥0.2MPa
Cooling Water Flow:
≥15L/Min
Gross Dimension:
1250*840*1000mm / 720*440*630mm
Gross Weight:
250kg
Highlight:

Iron Smelting Induction Melting Furnace

,

10kg Iron Smelting Induction Melting Furnace

,

50kg Iron Smelting Induction Melting Furnace

Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
USD 4000-5000 / set
Packaging Details
plywood case, 2 packages, 1250*840*1000mm / 720*440*630mm
Delivery Time
5-10 working days after receiving advanced payments
Payment Terms
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability
2000 sets per year
Product Description
10kg 20kg 30kg 50kg Iron Smelting Furnace Induction Melting Furnace
Product Specifications
AttributeValue
TypeInduction Melting Furnace
ApplicationSmelting iron, steel, copper, brass, gold, silver, aluminum
Rated Power45kw
Input Current80A
Voltage3-phase 380v, 50/60hz
Oscillation Frequency1-15KHZ
Connecting Wire35mm²
Control Switch3*120A
Ground Wire2mm²
Cooling Water Pressure≥0.2MPa
Cooling Water Flow≥15L/Min
Gross Dimension1250*840*1000mm / 720*440*630mm
Gross Weight250kg
45kw Electric Smelting Furnace Induction Melting Furnace
Introduction

Medium frequency induction melting furnace adopts IGBT as the core inverter. Alternating current in the coils melts the metals in the crucible and then heats the hot metal to the temperature needed. It is the heat treatment prior to forging, sintering and hot rolling in casting and melting industries.

45kw Metal Melting Furnace Iron Steel Copper Gold Silver Melting 0
Applications

The LSZ series induction melting furnace can melt the following materials:

  • Iron, pig iron, cast iron
  • Steel, stainless steel, cast steel, carbon steel and bearing steel
  • Precious metals like gold and silver
  • Copper, brass, bronze
  • Aluminum, aluminum alloy
  • Zinc, lead, tin, magnesium, nickel, titanium45kw Metal Melting Furnace Iron Steel Copper Gold Silver Melting 1
Melting Capacity
ModelRated PowerSteel, Stainless SteelCopper, Gold, SilverAluminum, Aluminum Alloy
LSZ-1515kw3kg10kg3kg
LSZ-2525kw5kg20kg5kg
LSZ-3535kw10kg30kg10kg
LSZ-4545kw18kg50kg18kg
LSZ-7070kw25kg100kg25kg
LSZ-9090kw40kg120kg40kg
LSZ-110110kw50kg150kg50kg
LSZ-160160kw100kg250kg100kg
Technical Parameters
ModelPowerInput CurrentVoltageOscillation FrequencyConnecting WireControl Switch
LSZ-1515kw18A3-phase 380V, 50/60 Hz1-15KHz10mm²3*40A
LSZ-2525kw36A3-phase 380V, 50/60 Hz1-15KHz10mm²3*60A
LSZ-3535kw57A3-phase 380V, 50/60 Hz1-15KHz16mm²3*80A
LSZ-4545kw80A3-phase 380V, 50/60 Hz1-15KHz35mm²3*120A
LSZ-7070kw110A3-phase 380V, 50/60 Hz1-15KHz50mm²3*150A
LSZ-9090kw140A3-phase 380V, 50/60 Hz1-15KHz75mm²3*225A
LSZ-110110kw160A3-phase 380V, 50/60 Hz1-15KHz90mm²3*225A
LSZ-160160kw240A3-phase 380V, 50/60 Hz1-15KHz120mm²3*300A
Key Features
  • IGBT modules
  • Higher reliability and lower maintenance cost
  • 100% Duty cycle - continuous working at maximum output power
  • Display heating power, heating current and oscillation frequency
  • Simple installation that can be done by unprofessional persons
  • Crucible changing is quite easy, for different melting materials
  • Continuous heating ability for 24 hours
Certificates
45kw Metal Melting Furnace Iron Steel Copper Gold Silver Melting 2 45kw Metal Melting Furnace Iron Steel Copper Gold Silver Melting 3
45kw Metal Melting Furnace Iron Steel Copper Gold Silver Melting 4
